QAV250 FPV Racing Drone Frame – 250mm Carbon Fiber

Description

The QAV250 Drone Frame is a popular 250mm FPV racing frame built for speed, agility, and durability.
Made from high-quality carbon fiber, this frame offers excellent strength-to-weight ratio and superior crash resistance, making it ideal for FPV racing and freestyle flying.

Its compact design supports high-performance brushless motors, FPV cameras, and modern F4/F7 flight controllers, making QAV250 a trusted choice for professional and hobby FPV pilots.

---

⭐ Key Features

• Strong carbon fiber construction

• Lightweight & crash-resistant

• Compact 250mm racing design

• Supports FPV camera & VTX

• Clean wiring and easy assembly

• Ideal for high-speed FPV drones

---

🔧 Technical Specifications

• Frame Model: QAV250

• Frame Type: FPV Racing Quadcopter

• Wheelbase: 250mm

• Material: Carbon Fiber

• Arm Thickness: ~4mm

• Top/Bottom Plate Thickness: ~2mm

• Supported Propeller Size: 5″ – 6″

• FC Mounting: 30.5 × 30.5mm

• Color: Carbon Black

---

🔌 Compatibility

• Flight Controllers: F4 / F7 / F405 / F722 etc

• Motors: 22xx / 23xx Brushless Motors

• ESCs: 20A – 50A (4in1 or individual)

• Battery: 3S – 4S Li-Po

• FPV Camera: Standard FPV size

---

🎯 Applications

• FPV Racing Drones

• Freestyle FPV Builds

• DIY High-Speed Quadcopters

• Professional Drone Projects

• FPV Training & Practice

---

📦 Package Includes

• 1 × QAV250 Carbon Fiber Drone Frame Kit

• All necessary screws & spacers
